← All opening-requirement comparisons
Opening-requirement comparison · sources reviewed 2026-09-21
Bosch SHX78CM5N vs Miele G5056SCVISF: three different published axes
These two premium 24-inch-category models publish different requirements on every axis. The Bosch SHX78CM5N's required-cutout table asks for 33 7/8 in high, 24 in wide and 24 in deep. The Miele G5056SCVISF's published cavity is 33 3/4 in high (up to an explicit 36 1/4 in maximum), 23 5/8 in wide and 22 1/2 in deep — the shallower and narrower documented minimums of the two, with the taller documented reach.
| Requirement | Bosch SHX78CM5N | Miele G5056SCVISF |
|---|---|---|
| Minimum opening height | 33 7/8 in | 33 3/4 in |
| Maximum opening height | Not verified | 36 1/4 in |
| Minimum opening width | 24 in | 23 5/8 in |
| Maximum opening width | Not verified | Not verified |
| Minimum opening depth | 24 in | 22 1/2 in |
| Front clearance | Not verified | Not verified |
| Corner clearance | Not verified | Not verified |
What is equal
Neither record has a verified front-clearance requirement, and both are 24-inch nominal-category, non-panel-ready models. Nominal category is a label, not a measurement.
Review gates on these records
- SHX78CM5N is an installer-review-only record: our lookup never returns it as an automatic dimensional candidate.
- SHX78CM5N: Candidate requires installer review of site conditions, utilities, panel or drawer clearance; do not enable automatic fit from this research batch.
- G5056SCVISF is an installer-review-only record: our lookup never returns it as an automatic dimensional candidate.
- G5056SCVISF: Candidate requires installer review of site conditions, utilities, panel or drawer clearance; do not enable automatic fit from this research batch.
- G5056SCVISF: Manufacturer product table verified; exact installation drawing and Abt SF suffix listing not yet verified.
Unresolved limits and unknowns
Both records are research additions that our lookup holds at installer review; neither is cleared for automatic fit results. The Miele record additionally awaits its installation-diagram review, and its retailer listing identity is unverified. The Bosch maximum opening height is not verified. A shallower published minimum depth is not a license to order for a shallow cabinet without the model-specific installation documents.
Documented smaller or conditional configurations
These published alternatives never become automatic matches; each needs installer review of the applicable document.
- SHX78CM5N: width from 23 5/8 in to 24 1/4 in — Published drawing range; 24-inch table width retained as conservative reviewed requirement. Smaller widths remain installer review only. Source
Body dimensions are context, not requirements
| Body | SHX78CM5N | G5056SCVISF |
|---|---|---|
| Height | 33 7/8 in | 33 3/4 in |
| Width | 23 9/16 in | 23 5/8 in |
| Depth | 23 3/4 in | 21 3/4 in |
Feature context from manufacturer specifications
SHX78CM5N features
- Sound rating
- 42 dBA
- Place settings
- 16
- Racks
- 3
- Drying system
- CrystalDry®, PureDry®
- Annual energy
- 240 kWh/year
- Connectivity
- Yes
Manufacturer specifications, checked September 20, 2026. Annual energy is a published estimate; sound ratings and drying names are not our test results.
Worth considering
- Three listed racks provide a separate level for smaller items.
- Published 42 dBA rating: a lower-noise option within this catalog.
- Manufacturer lists capacity for 16 place settings.
G5056SCVISF features
- Sound rating
- 44 dB(A)
- Place settings
- Not verified
- Racks
- Not verified
- Drying system
- Not verified
- Annual energy
- Not verified
- Connectivity
- Not verified
Manufacturer specifications, checked September 20, 2026. Annual energy is a published estimate; sound ratings and drying names are not our test results.
Worth considering
- Published 44 dBA rating: a lower-noise option within this catalog.
This is a document-based comparison of published opening requirements, not a physical installation test, a performance ranking or a fit guarantee. Results from our lookup are dimensional candidates; installation conditions always remain to verify.
