Bosch SGV78C53UC cabinet opening requirements

Questions people ask about the SGV78C53UC

The answers come only from the manufacturer documents linked on this page and the lookup's three outcomes.

What cabinet opening does the Bosch SGV78C53UC need?

The reviewed manufacturer document lists a minimum cabinet opening of 32 1/8 in high, 24 in wide and 24 in deep for the Bosch SGV78C53UC. Each figure links to its source in the table on this page. This record is held for installer review, so the lookup never returns it as an automatic candidate.

Is the SGV78C53UC a standard 24-inch dishwasher?

Bosch places the SGV78C53UC in the 24-inch category. That label describes the cabinet class, not the cutout: the reviewed minimum opening width is 24 in, and the appliance body is 23 9/16 in wide. Use the opening requirement, never the label, when you compare it with your cabinet.

Will the SGV78C53UC fit my opening?

Only your measurements can answer that. Enter the opening's height, width and depth in the lookup; the SGV78C53UC comes back as a dimensional candidate, an installer-review item or outside the published requirements, and because this record is held for installer review it never appears as an automatic candidate. None of the three outcomes is a fit guarantee: mounting, utilities, floor level, trim, panel weight and door swing stay with the installer.

How tall is the SGV78C53UC, and is that the opening height?

The manufacturer lists the SGV78C53UC appliance body at 32 1/16 in high. The body height is not the opening requirement: the minimum opening height on record is 32 1/8 in. Measure from the finished floor to the counter underside at several points and use the smallest reading.

Why is the SGV78C53UC held for installer review?

It carries a blocking review gate: Installer must verify finished opening, leveling range, insertion path, connections and door clearances; this research is not an installation guarantee. Exact model named on9/26 specification; p2 drawing visually reviewed. Opening height is32 1/8in, not32 1/16in appliance height. Maximum cabinet-opening height is not inferred from maximum appliance height. Custom panel is required; panel height, thickness, weight and swing must be reviewed against drawing. Drawing permits23 5/8in cabinet width only without decor strips; retain24in primary width and require installer for narrower configuration. The gate stays visible on this page until the evidence resolves.
