ASKO DBI564PS cabinet opening requirements

Questions people ask about the DBI564PS

The answers come only from the manufacturer documents linked on this page and the lookup's three outcomes.

What cabinet opening does the ASKO DBI564PS need?

The reviewed manufacturer document lists a minimum cabinet opening of 32 11/16 in high, 24 in wide and 21 7/8 in deep for the ASKO DBI564PS. Each figure links to its source in the table on this page. This record is held for installer review, so the lookup never returns it as an automatic candidate.

Is the DBI564PS a standard 24-inch dishwasher?

ASKO places the DBI564PS in the 24-inch category. That label describes the cabinet class, not the cutout: the reviewed minimum opening width is 24 in, and the appliance body is 23 15/16 in wide. Use the opening requirement, never the label, when you compare it with your cabinet.

Will the DBI564PS fit my opening?

Only your measurements can answer that. Enter the opening's height, width and depth in the lookup; the DBI564PS comes back as a dimensional candidate, an installer-review item or outside the published requirements, and because this record is held for installer review it never appears as an automatic candidate. None of the three outcomes is a fit guarantee: mounting, utilities, floor level, trim, panel weight and door swing stay with the installer.

How tall is the DBI564PS, and is that the opening height?

The manufacturer lists the DBI564PS appliance body at 32 11/16 in high. The body height is not the opening requirement: the minimum opening height on record is 32 11/16 in. Measure from the finished floor to the counter underside at several points and use the smallest reading.

Why is the DBI564PS held for installer review?

It carries a blocking review gate: Installer must verify finished opening, leveling range, insertion path, connections and door clearances; this research is not an installation guarantee. Exact Abt listing not found in this research; no Abt merchant or commission claim may be shown. Two documented configurations. Standard installation needs a 32 11/16 in minimum niche. A 32 5/16 in (820 mm) niche is possible only with the trim kit removed, which the installation drawing requires below 32 7/8 in (835 mm). The separate 32 1/4 in ADA figure is a modified appliance height, not a cavity. The installer must select and verify one configuration. Do not market32 1/4in as the required opening: installation drawing says32 5/16in. US model page links these exact product-code742941 documents. No integrated custom panel may be fitted; framed cabinet filler and trim changes require installer. Primary opening height resolved 2026-09-21 to the 32 11/16 in standard-configuration niche minimum, with the 32 5/16 in trim-removed niche retained as a documented alternative. Niche width 24 in (609 mm) and niche depth 21 7/8 in (555 mm) are confirmed by both the product sheet and instructions p39. Framed cabinets need a minimum 3 1/2 in (89 mm) finished return on all sides. The gate stays visible on this page until the evidence resolves.

Does the DBI564PS have a smaller published cutout?

Yes. The published drawing also shows a smaller configuration. The lookup screens on the stricter published value; the smaller configuration stays an installer-review result, never an automatic match.
